Reliable CO2 Cylinders for Superior Beverage Dispensing
Designed for efficiency and durability, USA Cylinder’s CO2 cylinders provide a consistent and reliable gas supply for a wide range of beverage applications. Whether you’re dispensing soft drinks, craft beer, or sparkling water, our cylinders ensure peak performance in every pour.
Our Gas Cylinders
- Precision Engineering – Guaranteed to meet the highest industry standards for beverage-grade CO2 applications
- Optimal Gas Retention – Seamless construction and superior materials maintain CO2 purity and pressure stability
- Versatile Compatibility – Ideal for bars, restaurants, breweries, and soda fountains
- Lightweight & Corrosion-Resistant – Easy handling with long-lasting durability
- Custom Branding Options – Enhance brand recognition with custom labels, colors, and graphics
Trusted by beverage professionals across the industry, USA Cylinder’s CO2 cylinders deliver reliability and quality with every use.
Carbon Dioxide Specifications
DOT-3AL / TC-3ALM
| Part# | Capacity | Diameter | Length | Weight | CO2 | Nitrogen | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| cu in | lbs | liters | in | mm | in | mm | lbs | kgs | lbs | kgs | cu ft | |
| B50 | 2035 | 73.5 | 33.3 | 8.6 | 218.4 | 46.3 | 1175 | 48.3 | 21.9 | 50 | 22.7 | 144 |
| B35 | 1426 | 51.5 | 23.4 | 8 | 203.2 | 37.8 | 960 | 35.2 | 16 | 35 | 15.9 | 100.9 |
| B22 | 901 | 32.5 | 14.7 | 8 | 203.2 | 25.1 | 638 | 25.3 | 11.5 | 22 | 10 | 63.5 |
| B20 | 814 | 29.4 | 13.3 | 8 | 203.2 | 23.2 | 589 | 23.7 | 10.8 | 20 | 9.1 | 57.6 |
| B15 | 612 | 22.1 | 10 | 6.89 | 175 | 23.1 | 587 | 16.8 | 7.6 | 15 | 6.8 | 43.3 |
| B10 | 407 | 14.7 | 6.7 | 6.89 | 175 | 16.5 | 419 | 12.6 | 5.7 | 10 | 4.5 | 29 |
| B5 | 203 | 7.4 | 3.4 | 5.25 | 133.4 | 14.2 | 361 | 6.3 | 2.9 | 5 | 2.3 | 14.5 |
| B2.5 | 102 | 3.7 | 1.7 | 4.38 | 111.3 | 10.3 | 262 | 3.3 | 1.5 | 2.5 | 1.1 | 7.2 |
ISO7866
| Part # | Capacity | Test Pressure | Diameter | Length | Weight | CO2 |
|---|---|---|---|---|---|---|
| liters | bar | mm | mm | kgs | kgs | |
| 9273 | 8 | 250 | 160 | 605 | 8.4 | 6 |
| 9274 | 13.4 | 250 | 204 | 632 | 13.9 | 10 |
Service Pressure: – 1800 psi / 124 bar
Specification: – DOT-3AL & TC-3ALM designed – ISO design cylinders are available
Alloy: – Manufactured from high strength aluminum alloy 6061-T6
Threads: – B5 & larger supplied with 1.125-12 UNF thread, all others with .750-16 UNF thread – Other thread sizes available upon request
Markings: – As required by specification, inclusive of tare weight – Additional markings available upon request
Finish: – Standard finish is brushed body with unpainted crown
Graphics: – Logos or labels in silkscreen or Duragrafix available upon request
Common Configuration: – B10 and larger with valve & carrying handle, B5 and smaller with valve only – Caps & collars or dip tubes available upon request
questions?
Have questions about specs, customization, or anything else? Let us know—we’re here to help!
